プロダクト細部
起源の場所: 広東省、中国
ブランド名: YUSH
モデル番号: YSVC-2
支払及び船積みの言葉
最小注文数量: 1セット
価格: $10,000 / set
重さ: |
185kg |
力: |
10W |
電圧: |
110V/220V |
プリント基板の厚さ: |
0.3-3.5mm |
使用空気圧: |
0.5-0.7MPA |
機械サイズ: |
780×500×620mm |
コアコンポーネント: |
PLCの変速機、モーター、ポンプ |
最高の構成の高さ: |
50mm |
パネル剥離方法: |
空気圧駆動 |
制御操作: |
フットペダル |
パネルを外す速度: |
オペレータ依存 |
最小 PCB 厚さ: |
0.3mm |
最高PCBの厚さ: |
3.5mm |
調整可能なギャップ: |
はい |
振動レベル: |
なし |
重さ: |
185kg |
力: |
10W |
電圧: |
110V/220V |
プリント基板の厚さ: |
0.3-3.5mm |
使用空気圧: |
0.5-0.7MPA |
機械サイズ: |
780×500×620mm |
コアコンポーネント: |
PLCの変速機、モーター、ポンプ |
最高の構成の高さ: |
50mm |
パネル剥離方法: |
空気圧駆動 |
制御操作: |
フットペダル |
パネルを外す速度: |
オペレータ依存 |
最小 PCB 厚さ: |
0.3mm |
最高PCBの厚さ: |
3.5mm |
調整可能なギャップ: |
はい |
振動レベル: |
なし |
This precision PCB depaneling machine is engineered to carefully separate pre-scored printed circuit boards without inducing bending or tension stress. The system ensures sensitive SMD components remain undamaged throughout the depaneling process.
| PCB Depaneling Thickness | 0.3-3.5mm |
| Voltage and Power | 110V/220V - 10W |
| Working Air Pressure | 0.5-0.7Mpa |
| Machine Dimensions | 780×500×620mm |
| Machine Weight | 185Kg |
| Depaneling Speed | Dependent on operator skill level |
YUSH Electronic Technology Co., Ltd. was founded in 2004 and is located in Jiangsu, China's manufacturing hub. The company specializes in professional PCB separator and depaneling equipment manufacturing.
With advanced production equipment and an experienced development team (half with over 10 years in electronic equipment industry), YUSH has focused on PCB separation technology since 2004. The company prioritizes product quality, safety, and innovation, delivering high-performance, cost-effective solutions that improve production yields and enhance customer competitiveness.
YUSH offers a comprehensive range of PCB separation solutions including manual, motor-driven, pneumatic-driven, mold punching, and milling cutter router types. Their quality products at reasonable prices have gained worldwide recognition, establishing YUSH as one of China's leading PCB separator production bases.
