プロダクト細部
起源の場所: 江蘇省、中国
ブランド名: YUSH
支払及び船積みの言葉
最小注文数量: 1セット
価格: $5,300-5,800 / set
重さ: |
100kg |
電圧: |
220V |
X、Y速度: |
80M/分 |
Z軸の速度: |
35m/min |
工具容量: |
6〜300 |
梱包の詳細: |
20000〜200000回転/分 |
位置決め精度: |
±0.004mm |
繰り返し精度: |
±0.0025mm |
穴あけ精度: |
±0.018mm |
最小穴: |
4mil(φ0.1mm) |
最大穴: |
256mil(φ6.5mm) |
テーブルサイズ: |
6-635mm×772mm |
動作範囲: |
6-622mm×755mm |
消費電力: |
15KVA |
空気圧: |
6.5~7.5bar |
重さ: |
100kg |
電圧: |
220V |
X、Y速度: |
80M/分 |
Z軸の速度: |
35m/min |
工具容量: |
6〜300 |
梱包の詳細: |
20000〜200000回転/分 |
位置決め精度: |
±0.004mm |
繰り返し精度: |
±0.0025mm |
穴あけ精度: |
±0.018mm |
最小穴: |
4mil(φ0.1mm) |
最大穴: |
256mil(φ6.5mm) |
テーブルサイズ: |
6-635mm×772mm |
動作範囲: |
6-622mm×755mm |
消費電力: |
15KVA |
空気圧: |
6.5~7.5bar |
| Serial Number | Name | Specifications and Models | Quantity |
|---|---|---|---|
| 1. | Host Machine | YS-F6MH | 1 set |
| 2. | Control System | Sieb & Meyer Control System | 1 set |
| 3. | Linear Motor (X, Y, Z) | High Performance Linear Motor Drive | 9 sets |
| 4. | Principal Axis | 200KRPM | 6 sets |
| 5. | Grating Scale | High Precision Grating Ruler (0.5μm resolution) | 9 sets |
| 6. | Guide Element | Imported High Precision Linear Guide Rail | 9 sets |
| 7. | Broken Tool Detection | Capacitive Cutter Detection | 6 sets |
| 8. | Tool Measuring System | Mingwei Tool Detector | 6 sets |
| 9. | Press Foot Switching | Flat Press Foot Switch | 6 sets |
| 10. | Dryer | Inlet Drier | 1 set |
| 11. | Air Holder | 70L Gas Storage Tank | 1 set |
| 12. | Display | Liquid Crystal Display | 1 set |
| X,Y Maximum Moving Speed | 80m/min |
| Z-axis Maximum Velocity | 35m/min |
| Tool Magazine Capacity | 6-300 |
| X, Y, Z Axis Measurement System | High Precision Grating Ruler (0.5μm resolution) |
| Positioning Clamping System | SMC Pneumatic Automatic Positioning Clamp |
| Broken Tool Detection System | Capacitive Cutter Detection |
| Spindle Speed | 20,000-200,000 rpm |
| Positioning Accuracy | ±0.004mm |
| Repeated Positioning Accuracy | ±0.0025mm |
| Drilling Accuracy | ±0.018mm |
| Depth Control Accuracy (Optional) | ±0.015mm |
| Minimum Hole Diameter | 4mil (φ0.1mm) |
| Maximum Hole Diameter | 256mil (φ6.5mm) |
| Table Size | 6-635mm × 772mm |
| Effective Working Range | 6-622mm × 755mm (24.5" × 29.7") |
| Power Source | 3PH-AC380V+N+PE, 50/60Hz |
| Maximum Power Consumption | 15KVA |
| Air Pressure | 6.5-7.5bar |
| Noise | ≤75dBA |
| Operating Temperature | 20℃-24℃ |
| Operating Humidity | 45-65% |
| Overall Dimensions (L × W × H) | 4700mm × 2000mm × 1610mm |
